HIGH PRECISION ULTRASONIC WALL
THICKNESS GAUGE
ONLY FROM ONE SIDE
|
| |
MG5 SERIES (Microcontroller Based) : MG5 & MG5-P |
| |
Useful for Testing of Pipelines, Coils & Tubes, Pressure
Vessels, Reactors, Gas Cylinders, Condensors, Boilers, Distillation Columns, Storage Tanks, Turbines, Shiphulls, Heat Exchangers, Pumps, Valves, Rolled Sheets, Glass Containers, Plastic Tanks & Parts.
Testing Materials : Steel (Mild Steel, S.S., Cast Steel, Cast Iron and Alloys of Steel), Aluminium, Copper, Lead, Tin, Brass, Alloys, Plastics (PVC, PP, LDPE, HDPE, PET), Glass, Ceramic. |
|
MODEL - MG5
( MICROCONTROLLER BASED ) |
|
MODEL - MG5P
( MICROCONTROLLER BASED ) |
|
| FEATURES: |
• Single Step Calibration
• Pocket Sized
• Feather Touch Keypad
• Velocity Setting or Measurement
• ± 0.1 mm & ± 0.01 mm Resolution
• Large LCD Display
• Built-in Calibration Block
• 100 Hours Battery Life
• Automatic V-path Correction
• NABL Traceable Calibration Certificate |
| |
| APPLICATIONS: |
• Raw Material Inspection
• Fabrication
• Quality Control
• Maintenance
• Corrosion and Erosion Survey |
| |
|
|
|
| MG5 & MG5-P TECHNICAL SPECIFICATIONS |
| Principle : |
Ultrasonic Pulse-echo |
| Applicable Materials : |
Steel (M.S., S.S, C.S., C.I., Aluminium, Copper, Lead, Tin, Other Metals, Brass, Monel, other Alloys, Hard Plastics (PVC, HDPE, LDPE, PP, PET), Glass, Ceramic etc. |
| Measurement Range : |
1.5 mm to 200 mm (In steel). Range depends on test material and probe. |
| Resolution : |
MG5 : 0.1 mm, MG5-P : 0.01mm |
| Accuracy : |
MG5 : ± 0.1mm up to 60 mm. Above 60 mm ±0.3%.(with Standard Probe DG-210).MG5-P : ± 0.03 mm up to 20 mm. ± 0.1 mm between 20 mm & 60 mm. Above 60 mm ±0.3%.(With Standard Probe DG-210). |
| Calibration : |
Single Point Calibration. |
| Velocity Range : |
1000 m/sec to 9990 m/sec |
| Keyboard : |
Soft Touch Keyboard with sealed keys. |
| Display : |
Large size LCD displays Thickness, Units, Velocity, Low-Bat Indication, Coupling Check. |
| V-Path Correction : |
Automatic V-Path correction for higher accuracy at lower readings. |
| Batteries : |
5 No. Pencil Dry Cells (AA) or Ni-Cd. |
| Operating Time : |
100 hours. (With Alkaline Cells). |
| Auto Timer Cutoff : |
Instrument switch-off after 5 minutes of idle use. |
| Low Battery : |
Low-Bat Indication in LCD Display. |
| Case : |
Light Aluminium Sturdy Case. |
| Size (Approx.) : |
80 mm (W) X155 mm (H) X 38 mm (D). |
| Weight (Approx.) : |
400 gms. (Including batteries) |
|
|
|
